swissTLM-Map (grey)

swissTLM-Map is an automatically generated map which offers a complement to the national maps in the scale range 1:5'000 to 1:10'000. swissTLM-Map is based on the data of the topographic landscape model swissTLM3D complemented by the contours and hillshade of the digital elevation model swissALTI3D.

Alternate title: Map swissTLM (grey)

Date (Publication): 2025-04-09

Date (Revision): 2025-03-05

Date (Creation): 2012-01-01

Edition: Version 2.3

Edition date: 2025-03-05

Citation identifier: ch.swisstopo.swisstlm3d-karte-grau

Citation identifier

No information provided.

Collective title: topographical landscape model (national survey)

Status: On going

Point of contact

Organisation name	Individual name	Electronic mail address	Website	Role
Federal Office of Topography swisstopo		geodata@swisstopo.ch	http://www.swisstopo.ch	Point of contact

Maintenance and update frequency: Annually

Maintenance note: The existing data was migrated into the TLM as a basis. The data is then updated based on an update cycle of 6 years and improvements and additions are made to the geometries and attributes. Parallel to the six-year update process, an annual update is carried out through the integration of data from so-called reference partners for selected topics. Initially, this annual update is implemented mainly for the administrative boundaries, buildings and road links. The official cadastral survey plays an important role as a reference partner in this process. The nomenclature for updating names are also integrated from the official cadastral survey.

GEMET

public transport
vector
geographic information system

geocat.ch

contour line
single object
landscape model
base map
opendata.swiss
GIS (Geographic Information System)
traffic network

GEMET - INSPIRE themes, version 1.0

Hydrography
Land cover
Geographical names

geocat.ch

FSDI Federal Spatial Data Infrastructure

geocat.ch

topography

GEMET

map chart

Use constraints: Other restrictions

Other constraints: NonCommercialAllowed-CommercialAllowed-ReferenceRequired

Aggregate Datasetindentifier: 73856ca2-f21d-4cc9-90f6-f3e8375555df

Association Type: Larger work citation

Spatial representation type: Grid

Denominator: 5000

Denominator: 25000

Language of dataset: ger

Character set: UTF8

Topic category

Imagery base maps earth cover

Extent

Description: Switzerland

Extent

Description: Liechtenstein

Reference system identifier: EPSG:21781

Reference system identifier: EPSG:2056

Reference system identifier: EPSG:5728

Distribution format

GeoTIFF (GEOTIFF) ()

OnLine resource

Protocol	Linkage	Name
MAP:Preview	https://map.geo.admin.ch/?layers=ch.swisstopo.swisstlm3d-karte-grau	Preview map.geo.admin.ch
OGC:WMS	https://wms.geo.admin.ch/?SERVICE=WMS&VERSION=1.3.0&REQUEST=GetCapabilities&lang=de	ch.swisstopo.swisstlm3d-karte-grau
OGC:WMTS	https://wmts.geo.admin.ch/EPSG/3857/1.0.0/WMTSCapabilities.xml?lang=de	ch.swisstopo.swisstlm3d-karte-grau

OnLine resource

Protocol	Linkage	Name
WWW:LINK	https://www.swisstopo.admin.ch/de/landschaftsmodell-swisstlm3d	swissTLM3D

OnLine resource

Protocol	Linkage	Name
CHTOPO:specialised-geoportal	http://map.geo.admin.ch/?Y=660000&X=190000&zoom=1&bgLayer=voidLayer&layers=ch.swisstopo.swisstlm3d-karte-grau&layers_opacity=1&layers_visibility=true&time_current=latest&lang=de

Hierarchy level: Dataset

Statement: Geometric accuracy: swissTLM3D (0.2 -1.5 m in all three dimensions for well-defined landscape features such as roads and buildings, 1 - 3 m in all three dimensions for landscape features which are not clearly defined such as forests)
